Cisco Telepresence MX800 Reference Guide

D15335.02 Cisco TelePresence MX700 and MX800 API Reference Guide CE8.0, FEBRUARY 2016.
Copyright © 2016 Cisco Systems, Inc. All rights reserved. 40
Cisco TelePresence MX700 and MX800
API Reference Guide
xConfiguration Audio Input Microphone [1..8] Equalizer Mode
Define the equalizer mode for the source that is connected to the microphone input.
Requires user role: ADMIN
Default value: Off
USAGE:
xConfiguration Audio Input Microphone n Equalizer Mod e: Mode
where
Mode : Off/On
Off: No equalizer.
On: Enable the equalizer for the source that is connected to the microphone input.
xConfiguration Audio Input Microphone [1..8] VideoAssociation
MuteOnInactiveVideo
The microphone can be associated with a video source on the video input connector, and
you can determine whether to play or mute audio depending on whether the video source is
presented or not. By default, audio is not muted.
Requires user role: ADMIN
Default value: On
USAGE:
xConfiguration Audio Input Microphone n VideoAssociation MuteOnInactiveVideo:
MuteOnInactiveVideo
where
MuteOnInactiveVideo : Off/On
Off: No video source is associated.
On: A video source is associated, and the audio will be muted if the associated video
source is not displayed.
xConfiguration Audio Input Microphone [1..8] VideoAssociation
VideoInputSource
Select the video input connector to associate the audio source with.
Requires user role: ADMIN
Default value: 1
USAGE:
xConfiguration Audio Input Microphone n VideoAssociation VideoInputSource:
VideoInputSource
where
VideoInputSource : 1/2/3/4/5
Select the video input connector to associate the audio source with.
xConfiguration Audio Input Microphone [1..8] Level
Define the level of the Microphone input connector.
See the Audio Level table in the Physical Interface Guide for Cisco TelePresence SX80 for a
complete overview of the values represented in dB.
Requires user role: ADMIN
Default value: 58
USAGE:
xConfiguration Audio Input Microphone n Level: Level
where
Level : Integer (0..70)
Select a value between 0 and 70, in steps of 1 dB.
Introduction
About the API
xConfiguration
Appendices
xCommand
xStatus

xConfiguration

Cisco Telepresence MX800 Specifications

General

Pan range	-90 - 60 °
Product type	Video conferencing service management system
Product color	White
Wall mountable	Yes
Tilt angle range	-14 - 12 °
Number of persons	- person(s)
Aspect ratio	16:9
Maximum frame rate	60 fps
Supported video modes	720p, 1080p
Video formats supported	H.261, H.263, H.264, H.265
Resolution at capture speed	1920x1080@60fps
Supported graphics resolutions	352 x 288, 512 x 288, 1024 x 576 (WSVGA), 1024 x 768 (XGA), 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA)
Megapixel	- MP
Sensor type	-
Digital zoom	2 x
Optical zoom	10 x
Image sensor size	- \
Closest focusing distance	1 m
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Display diagonal	70 \
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	591 W
Power consumption (typical)	571 W
