Cisco Telepresence MX800 Reference Guide

D15335.02 Cisco TelePresence MX700 and MX800 API Reference Guide CE8.0, FEBRUARY 2016.
Copyright © 2016 Cisco Systems, Inc. All rights reserved. 110
Cisco TelePresence MX700 and MX800
API Reference Guide
xCommand Peripherals Pairing DeviceDiscovery Start
Start device discovery to detect ISDN Links in the same network.
Requires user role: ADMIN
USAGE:
xCommand Peripherals Pairing DeviceDiscovery Start [AutoPairing: AutoPairing]
[DeviceType: DeviceTy pe] [Timeout: Timeout]
where
AutoPairing: On/Off
You can select to automatically pair the detected device to the endpoint.
DeviceType: ISDNLink
Only look for ISDN Link.
Timeout: Integer (3..60)
Set a maximum time for the search from 3 to 60 seconds.
xCommand Peripherals Pairing Pair
Pair an ISDN Link to an endpoint.
Requires user role: ADMIN
USAGE:
xCommand Peripherals Pairing Pair Mac Add ress: "MacAddress"
where
MacAddress: String (1, 1450)
Enter the MAC address for the ISDN Link you wish to pair to the endpoint.
xCommand Peripherals Pairing Unpair
Unpair endpoint from an ISDN Link, when the two have contact.
Requires user role: ADMIN
USAGE:
xCommand Peripherals Pairing Unpair M acAd d ress: "MacAddress"
where
MacAddress: String (1, 100)
MacAddress: Enter the MAC address for the ISDN Link you wish to unpair from the
endpoint.
xCommand Peripherals Purge
Force unpair an endpoint from an ISDN Link when a connection has been lost. Note: You must
also unpair the ISDN Link to be able to pair it to another endpoint.
Requires user role: USER
USAGE:
xCommand Peripherals Purge ID: "ID"
where
ID: String (1, 100)
Mac address of the ISDN Link in the format "xx:xx:xx:xx:xx:xx".
Introduction
About the API
xConfiguration
Appendices
xCommand
xStatus

xCommand

Cisco Telepresence MX800 Specifications

General

Pan range	-90 - 60 °
Product type	Video conferencing service management system
Product color	White
Wall mountable	Yes
Tilt angle range	-14 - 12 °
Number of persons	- person(s)
Aspect ratio	16:9
Maximum frame rate	60 fps
Supported video modes	720p, 1080p
Video formats supported	H.261, H.263, H.264, H.265
Resolution at capture speed	1920x1080@60fps
Supported graphics resolutions	352 x 288, 512 x 288, 1024 x 576 (WSVGA), 1024 x 768 (XGA), 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA)
Megapixel	- MP
Sensor type	-
Digital zoom	2 x
Optical zoom	10 x
Image sensor size	- \
Closest focusing distance	1 m
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Display diagonal	70 \
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	591 W
Power consumption (typical)	571 W
