xConfiguration Video Selfview Default OnMonitorRole
Define which monitor/output to display the main video source (self-view) on after a call. The
value reflects the monitor roles set for the different outputs in the Video Output Connector [n]
MonitorRole setting.
The setting applies both when self-view is displayed in full screen, and when it is displayed as
picture-in-picture (PiP), but only if the Video Monitors setting is set to Dual or Triple.
Requires user role: ADMIN
Default value: Current
USAGE:
xConfiguration Video Selfview Default OnMonitorRole: OnMonitorRole
where
OnMonitorRole : First/Second/Third/Current
First: The self-view picture will be shown on outputs with the Video Output Connector
[n] MonitorRole set to First.
Second: The self-view picture will be shown on outputs with the Video Output
Connector [n] MonitorRole set to Second.
Third: The self-view picture will be shown on outputs with the Video Output Connector
[n] MonitorRole set to Third.
Current: When leaving a call, the self-view picture will be kept on the same output as it
was during the call.
xConfiguration Video Selfview Default PIPPosition
Define the position on screen of the small self-view picture-in-picture (PiP) after a call. The
setting only takes effect when self-view is switched on (see the Video Selfview Default Mode
setting) and fullscreen view is switched off (see the Video Selfview Default FullscreenMode
setting).
Requires user role: ADMIN
Default value: Current
USAGE:
xConfiguration Video Selfview Default PIPPosition: PIP Position
where
PIPPosition : Current/UpperLeft/UpperCenter/UpperRight/CenterLeft/CenterRight/
LowerLeft/LowerRight
Current: The position of the self-view PiP will be kept unchanged when leaving a call.
UpperLeft: The self-view PiP will appear in the upper left corner of the screen.
UpperCenter: The self-view PiP will appear in the upper center position.
UpperRight: The self-view PiP will appear in the upper right corner of the screen.
CenterLeft: The self-view PiP will appear in the center left position.
CentreRight: The self-view PiP will appear in the center right position.
LowerLeft: The self-view PiP will appear in the lower left corner of the screen.
LowerRight: The self-view PiP will appear in the lower right corner of the screen.
