D15335.02 Cisco TelePresence MX700 and MX800 API Reference Guide CE8.0, FEBRUARY 2016.
Copyright © 2016 Cisco Systems, Inc. All rights reserved. 104
Cisco TelePresence MX700 and MX800
API Reference Guide
Cameras commands
xCommand Cameras SpeakerTrack Activate
Activate SpeakerTrack mode. Requires that xConfiguration Cameras SpeakerTrack Mode is set
to Auto (default).
This setting applies only when using a Cisco TelePresence SpeakerTrack 60 camera.
The SpeakerTrack 60 camera assembly consists of two cameras and uses an audio tracking
technique that finds and captures a close-up of the active speaker. When a change of speaker
is detected, the system can switch automatically between the two cameras to always show the
best camera view.
Requires user role: USER
USAGE:
xCommand Cameras SpeakerTrack Activate
xCommand Cameras SpeakerTrack Deactivate
Deactivate SpeakerTrack mode.
This setting applies only when using a Cisco TelePresence SpeakerTrack 60 camera.
The SpeakerTrack 60 camera assembly consists of two cameras and uses an audio tracking
technique that finds and captures a close-up of the active speaker. When a change of speaker
is detected, the system can switch automatically between the two cameras to always show the
best camera view.
Requires user role: USER
USAGE:
xCommand Cameras SpeakerTrack Deactivate
xCommand Cameras SpeakerTrack Diagnostics Start
Starts diagnostics on the SpeakerTrack cameras’ tracking.
Requires user role: ADMIN
USAGE:
xCommand Cameras SpeakerTrack Diagnostics Start Tracking: Tracking
where
Tracking: On/Off
On: Displays diagnostics from both cameras simultaneously. In this mode the tracking is
determined by who is talking in the room identical to SpeakerTrack’s standard behaviour.
Off: Displays diagnostics from one camera at a time. Diagnostics is switched from one
camera to the other in 15 seconds intervals, and camera related diagnostics are shown
for the active camera. Both cameras stay in full wide position. Use Tracking: Off when
you wish to see the tracking diagnostics from one camera at a time.
xCommand Cameras SpeakerTrack Diagnostics Stop
Stops diagnostics on the SpeakerTrack cameras.
Requires user role: ADMIN
USAGE:
xCommand Cameras SpeakerTrack Diagnostics Stop
Introduction
About the API
xConfiguration
Appendices
xCommand
xStatus

xCommand

Cisco Telepresence MX800 Specifications

General

Pan range	-90 - 60 °
Product type	Video conferencing service management system
Product color	White
Wall mountable	Yes
Tilt angle range	-14 - 12 °
Number of persons	- person(s)
Aspect ratio	16:9
Maximum frame rate	60 fps
Supported video modes	720p, 1080p
Video formats supported	H.261, H.263, H.264, H.265
Resolution at capture speed	1920x1080@60fps
Supported graphics resolutions	352 x 288, 512 x 288, 1024 x 576 (WSVGA), 1024 x 768 (XGA), 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA)
Megapixel	- MP
Sensor type	-
Digital zoom	2 x
Optical zoom	10 x
Image sensor size	- \
Closest focusing distance	1 m
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Display diagonal	70 \
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	591 W
Power consumption (typical)	571 W
