Cisco Telepresence MX800 Reference Guide

D15335.02 Cisco TelePresence MX700 and MX800 API Reference Guide CE8.0, FEBRUARY 2016.
Copyright © 2016 Cisco Systems, Inc. All rights reserved. 83
Cisco TelePresence MX700 and MX800
API Reference Guide
xConfiguration Video Input Connector [1..5] Name
Define a name for the video input connector.
Requires user role: ADMIN
Default value: Connector 1: "Camera 1" Connector 2: "" for single camera systems,
"Camera 2" for dual camera systems Connector 3: "PC (HDMI)" Connector 4: "PC (VGA)"
Connector 5: ""
USAGE:
xConfiguration Video Input Connector n Na me: "Name"
where
n : Index that identifies the input connector. Range: 1..5
Name : String (0, 50)
Name for the video input connector.
xConfiguration Video Input Connector [1..5] Quality
When encoding and transmitting video there is a trade-off between high resolution and high
frame rate. For some video sources it is more important to transmit high frame rate than high
resolution and vice versa. This setting specifies whether to give priority to high frame rate or to
high resolution.
Requires user role: ADMIN
Default value: Connector 1, 2, 5: Motion Connector 3, 4: Sharpness
USAGE:
xConfiguration Video Input Connector n Quality: Quality
where
n : Index that identifies the input connector. Range: 1..5
Quality : Motion/Sharpness
Motion: Gives the highest possible frame rate. Used when there is a need for higher
frame rates, typically when a large number of participants are present or when there is
a lot of motion in the picture.
Sharpness: Gives the highest possible resolution. Used when you want the highest
quality of detailed images and graphics.
xConfiguration Video Input Connector [1..4] PresentationSelection
Define how the video system will behave when you connect a presentation source to the video
input. In general, any input source can be used as a presentation source; normally, the main
camera will not be used as a presentation source.
If the video system is in standby mode, it will wake up when you connect a presentation source.
Note that sharing the presentation with the far end always requires additional action (press
Share on the user interface).
Requires user role: ADMIN
Default value: Connector 1: Manual Connector 2: OnConnect for single camera system,
Manual for dual camera systems Connector 3, 4: OnConnect
USAGE:
xConfiguration Video Input Connector n PresentationSelection:
PresentationSelection
where
n : Index that identifies the input connector. Range: 1..4
PresentationSelection : Connector 1: Manual Connector 2: Manual/OnConnect for single
camera systems, and Manual for dual camera systems Connector 3, 4: Manual/OnConnect
Manual: In manual mode, the contents of the video input will not be presented on the
screen until you choose it from the user interface.
OnConnect: When in on-connect mode, the content on the video input will be
presented on screen when a cable is connected. Otherwise, the behavior is the same
as in manual mode.
Introduction
About the API
xConfiguration
Appendices
xCommand
xStatus

xConfiguration

Cisco Telepresence MX800 Specifications

General

Pan range	-90 - 60 °
Product type	Video conferencing service management system
Product color	White
Wall mountable	Yes
Tilt angle range	-14 - 12 °
Number of persons	- person(s)
Aspect ratio	16:9
Maximum frame rate	60 fps
Supported video modes	720p, 1080p
Video formats supported	H.261, H.263, H.264, H.265
Resolution at capture speed	1920x1080@60fps
Supported graphics resolutions	352 x 288, 512 x 288, 1024 x 576 (WSVGA), 1024 x 768 (XGA), 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA)
Megapixel	- MP
Sensor type	-
Digital zoom	2 x
Optical zoom	10 x
Image sensor size	- \
Closest focusing distance	1 m
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Display diagonal	70 \
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	591 W
Power consumption (typical)	571 W
