D15335.02 Cisco TelePresence MX700 and MX800 API Reference Guide CE8.0, FEBRUARY 2016.
Copyright © 2016 Cisco Systems, Inc. All rights reserved. 107
Cisco TelePresence MX700 and MX800
API Reference Guide
Diagnostics commands
xCommand Diagnostics Run
This command runs self-diagnostics commands on the system.
Requires user role: ADMIN
USAGE:
xCommand Diagnostics Run [ResultSet: ResultSet]
where
ResultSet: Alerts/All/None
You can filter the diagnostics results to alerts, all or none. If not set, the result will show
all results.
Dial commands
xCommand Dial
Dial out from the system. Returns information about the CallId and ConferenceId, which are
required for some of the other commands.
Requires user role: USER
USAGE:
xCommand Dial Num ber: "Number" [Protocol: Protocol] [CallRate: CallRate]
[CallTy p e: CallTy pe] [BookingId: "BookingId"] [Appearance: Appearance]
[DisplayName: "DisplayName"]
where
Number: String (0, 255)
Enter the number or address.
Protocol: H320/H323/Sip
Select the call protocol.
CallRate: Integer (64..6000)
Set the call rate.
CallType: Audio/Video
Select the call type.
BookingId: String (0, 255)
Any identifier that an external booking system (e.g. TMS, CTS-MAN) can use for its
own references to match placed calls with the booking systems internal identifier for a
meeting. This can be any string, e.g. a GUID. The booking Id is supplied in call logs, call
events etc for the call.
Appearance: Integer (1..999999999)
Internal usage only.
DisplayName: String (0, 255)
The display name of the remote participant.
