D15335.02 Cisco TelePresence MX700 and MX800 API Reference Guide CE8.0, FEBRUARY 2016.
Copyright © 2016 Cisco Systems, Inc. All rights reserved. 65
Cisco TelePresence MX700 and MX800
API Reference Guide
xConfiguration NetworkServices SNMP Mode
SNMP (Simple Network Management Protocol) is used in network management systems to
monitor network-attached devices (routers, servers, switches, projectors, etc) for conditions
that warrant administrative attention. SNMP exposes management data in the form of variables
on the managed systems, which describe the system configuration. These variables can then
be queried (set to ReadOnly) and sometimes set (set to ReadWrite) by managing applications.
Requires user role: ADMIN
Default value: ReadOnly
USAGE:
xConfiguration NetworkServices SNMP Mode: Mode
where
Mode
: Off/ReadOnly/ReadWrite
Off: Disable the SNMP network service.
ReadOnly: Enable the SNMP network service for queries only.
ReadWrite: Enable the SNMP network service for both queries and commands.
xConfiguration NetworkServices SNMP Host [1..3] Address
Define the address of up to three SNMP Managers.
The system's SNMP Agent (in the codec) responds to requests from SNMP Managers (a PC
program etc.), for example about system location and system contact. SNMP traps are not
supported.
Requires user role: ADMIN
Default value: ""
USAGE:
xConfiguration NetworkServices SNMP Host n Ad d ress: "Address"
where
n
: Identifies the SNMP host. Maximum three SNMP hosts are allowed. Range: 1..3
Address
: String (0, 64)
A valid IPv4 address, IPv6 address or DNS name.
xConfiguration NetworkServices SNMP CommunityName
Define the name of the Network Services SNMP Community. SNMP Community names are
used to authenticate SNMP requests. SNMP requests must have a password (case sensitive)
in order to receive a response from the SNMP Agent in the codec. The default password is
"public". If you have the Cisco TelePresence Management Suite (TMS) you must make sure the
same SNMP Community is configured there too. NOTE: The SNMP Community password is
case sensitive.
Requires user role: ADMIN
Default value: ""
USAGE:
xConfiguration NetworkServices SNMP Com munityNa me: "CommunityName"
where
CommunityName
: String (0, 50)
The SNMP community name.
xConfiguration NetworkServices SNMP SystemContact
Define the name of the Network Services SNMP System Contact.
Requires user role: ADMIN
Default value: ""
USAGE:
xConfiguration NetworkServices SNMP Syste mContact: "SystemContact"
where
SystemContact
: String (0, 50)
The name of the SNMP system contact.
