D15335.02 Cisco TelePresence MX700 and MX800 API Reference Guide CE8.0, FEBRUARY 2016.
Copyright © 2016 Cisco Systems, Inc. All rights reserved. 38
Cisco TelePresence MX700 and MX800
API Reference Guide
xConfiguration Audio Input Line [1..4] VideoAssociation VideoInputSource
The audio source can be associated with a video source on the video input connector.
Requires user role: ADMIN
Default value: Line [1, 2]: 4 Line[3, 4]: 1
USAGE:
xConfiguration Audio Input Line n VideoAssociation VideoInputSource:
VideoInputSource
where
VideoInputSource : 1/2/3/4/5
Select the video input connector to associate the audio source with.
xConfiguration Audio Input Line [1..4] Channel
Define whether the audio source on the line input is a mono signal or part of a multichannel
signal.
Requires user role: ADMIN
Default value: Left
USAGE:
xConfiguration Audio Input Line n Chan nel: Channel
where
Channel : Left/Mono/Right
Left: The Audio Line input signal is the left channel of a stereo signal.
Mono: The Audio Line input signal is a mono signal.
Right: The Audio Line input signal is the right channel of a stereo signal.
xConfiguration Audio Input Line [1..4] Level
Define the level of the audio source on the line input connector.
See the Audio Level table in the Physical Interface Guide for Cisco TelePresence SX80 for a
complete overview of the values represented in dB.
Requires user role: ADMIN
Default value: 10
USAGE:
xConfiguration Audio Input Line n Level: Level
where
Level : Integer (0..24)
Select a value between 0 and 24, in steps of 1 dB.
xConfiguration Audio Input Line [1..4] Mode
Define the mode for the audio input line.
Requires user role: ADMIN
Default value: On
USAGE:
xConfiguration Audio Input Line n Mode: Mode
where
Mode : Off/On
Off: Disable the Audio Line input.
On: Enable the Audio Line input.
Introduction
About the API
xConfiguration
Appendices
xCommand
xStatus

xConfiguration

Cisco Telepresence MX800 Specifications

General

Pan range	-90 - 60 °
Product type	Video conferencing service management system
Product color	White
Wall mountable	Yes
Tilt angle range	-14 - 12 °
Number of persons	- person(s)
Aspect ratio	16:9
Maximum frame rate	60 fps
Supported video modes	720p, 1080p
Video formats supported	H.261, H.263, H.264, H.265
Resolution at capture speed	1920x1080@60fps
Supported graphics resolutions	352 x 288, 512 x 288, 1024 x 576 (WSVGA), 1024 x 768 (XGA), 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA)
Megapixel	- MP
Sensor type	-
Digital zoom	2 x
Optical zoom	10 x
Image sensor size	- \
Closest focusing distance	1 m
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Display diagonal	70 \
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	591 W
Power consumption (typical)	571 W
