Cisco Telepresence MX800 Reference Guide

D15335.02 Cisco TelePresence MX700 and MX800 API Reference Guide CE8.0, FEBRUARY 2016.
Copyright © 2016 Cisco Systems, Inc. All rights reserved. 75
Cisco TelePresence MX700 and MX800
API Reference Guide
xConfiguration SIP ListenPort
Turn on or off the listening for incoming connections on the SIP TCP/UDP ports. If turned off,
the endpoint will only be reachable through the SIP registrar (CUCM or VCS). It is recom-
mended to leave this setting at its default value.
Requires user role: ADMIN
Default value: On
USAGE:
xConfiguration SIP ListenPort: ListenPort
where
ListenPort : Off/On
Off: Listening for incoming connections on the SIP TCP/UDP ports is turned off.
On: Listening for incoming connections on the SIP TCP/UDP ports is turned on.
xConfiguration SIP Proxy [1..4] Address
The Proxy Address is the manually configured address for the outbound proxy. It is possible to
use a fully qualified domain name, or an IP address. The default port is 5060 for TCP and UDP
but another one can be provided.
Requires user role: ADMIN
Default value: ""
USAGE:
xConfiguration SIP Proxy n Ad d ress: "Address"
where
n : Index that identifies the proxy (maximum 4 proxys can be defined). Range: 1..4
Address : String (0, 255)
A valid IPv4 address, IPv6 address or DNS name.
xConfiguration SIP Turn Server
Define the address of the TURN (Traversal Using Relay NAT) server. It is used as a media relay
fallback and it is also used to discover the endpoint's own public IP address.
Requires user role: ADMIN
Default value: ""
USAGE:
xConfiguration SIP Turn Server: "Server"
where
Server : String (0, 255)
The preferred format is DNS SRV record (e.g. _turn._udp.<domain>), or it can be a valid
IPv4 or IPv6 address.
xConfiguration SIP Turn UserName
Define the user name needed for accessing the TURN server.
Requires user role: ADMIN
Default value: ""
USAGE:
xConfiguration SIP Turn UserName: "UserName"
where
UserName : String (0, 128)
A valid user name.
xConfiguration SIP Turn Password
Define the password needed for accessing the TURN server.
Requires user role: ADMIN
Default value: ""
USAGE:
xConfiguration SIP Turn Password: "Password"
where
Password : String (0, 128)
A valid password.
Introduction
About the API
xConfiguration
Appendices
xCommand
xStatus

xConfiguration

Cisco Telepresence MX800 Specifications

General

Pan range	-90 - 60 °
Product type	Video conferencing service management system
Product color	White
Wall mountable	Yes
Tilt angle range	-14 - 12 °
Number of persons	- person(s)
Aspect ratio	16:9
Maximum frame rate	60 fps
Supported video modes	720p, 1080p
Video formats supported	H.261, H.263, H.264, H.265
Resolution at capture speed	1920x1080@60fps
Supported graphics resolutions	352 x 288, 512 x 288, 1024 x 576 (WSVGA), 1024 x 768 (XGA), 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA)
Megapixel	- MP
Sensor type	-
Digital zoom	2 x
Optical zoom	10 x
Image sensor size	- \
Closest focusing distance	1 m
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Display diagonal	70 \
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	591 W
Power consumption (typical)	571 W
