Cisco Telepresence MX800 Reference Guide

D15335.02 Cisco TelePresence MX700 and MX800 API Reference Guide CE8.0, FEBRUARY 2016.
Copyright © 2016 Cisco Systems, Inc. All rights reserved. 46
Cisco TelePresence MX700 and MX800
API Reference Guide
xConfiguration Cameras Camera [1..7] Whitebalance Level
Define the white balance level. Requires the Cameras Camera [n] Whitebalance Mode to be set
to manual.
Requires user role: USER
Default value: 1
USAGE:
xConfiguration Cameras Camera n Whitebalance Level: Level
where
Level : Integer (1..16)
The white balance level.
xConfiguration Cameras Preset TriggerAutofocus
The current position (pan and tilt), zoom and focus are stored with a preset. Use this setting to
determine if the camera should refocus or use the focus value that is stored with the preset.
Requires user role: ADMIN
Default value: Auto
USAGE:
xConfiguration Cameras Preset TriggerAutofocus: TriggerAutofocus
where
TriggerAutofocus : Auto/Off/On
Auto: Whether the camera refocuses or not when selecting a preset, depends on the
camera type.
Off: The focus value that is stored with the preset will be used. The camera will not
refocus when selecting a preset.
On: The camera will refocus when selecting a preset. The focus value that is stored with
the preset may be overridden.
xConfiguration Cameras SpeakerTrack Mode
This setting applies only to systems with a dual camera (speaker track).
The dual camera assembly consists of two cameras and uses an audio tracking technique that
finds and captures a close-up of the active speaker. When a change of speaker is detected, the
system can switch automatically between the two cameras to always show the best camera
view. Refer to the Cameras SpeakerTrack TrackingMode setting for different switching modes.
Requires user role: USER
Default value: Auto
USAGE:
xConfiguration Cameras SpeakerTrack Mod e: Mode
where
Mode : Auto/Off
Auto: Speaker tracking is switched on. The cameras in the camera assembly behave
as one integrated unit that finds the active speaker and dynamically chooses the best
camera view.
Off: The cameras operate as two individual cameras. Speaker tracking is not used.
xConfiguration Cameras SpeakerTrack TrackingMode
This setting applies only to systems with a dual camera (speaker tracking), and when Cameras
SpeakerTrack Mode is set to Auto.
The speaker tracking algorithm can react to changes in two modes, one faster than the other.
The mode determines when the camera view will change to a new speaker.
Requires user role: USER
Default value: Auto
USAGE:
xConfiguration Cameras SpeakerTrack TrackingMode: TrackingMode
where
TrackingMode : Auto/Conservative
Auto: Normal tracking mode.
Conservative: The camera view will change to a new speaker later than in Normal mode.
Introduction
About the API
xConfiguration
Appendices
xCommand
xStatus

xConfiguration

Cisco Telepresence MX800 Specifications

General

Pan range	-90 - 60 °
Product type	Video conferencing service management system
Product color	White
Wall mountable	Yes
Tilt angle range	-14 - 12 °
Number of persons	- person(s)
Aspect ratio	16:9
Maximum frame rate	60 fps
Supported video modes	720p, 1080p
Video formats supported	H.261, H.263, H.264, H.265
Resolution at capture speed	1920x1080@60fps
Supported graphics resolutions	352 x 288, 512 x 288, 1024 x 576 (WSVGA), 1024 x 768 (XGA), 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA)
Megapixel	- MP
Sensor type	-
Digital zoom	2 x
Optical zoom	10 x
Image sensor size	- \
Closest focusing distance	1 m
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Display diagonal	70 \
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	591 W
Power consumption (typical)	571 W
