ComAp InteliCompact NT Reference Guide

InteliCompact
NT
, SW version 2.1
InteliCompact-NT-2.1-Reference Guide.pdf, ©ComAp – May 2015
165
Setpoint: Nominal Power
Group
Basic Settings
Range [units]
1 ... 32000 [kW]
Related
applications
All
Description
Nominal power of the gen-set. Generator overload protection is based on
this setpoint.
Setpoint: Nomin Current
Group
Basic Settings
Range [units]
1 ... 10000 [A]
Related
applications
All
Description
This is the current limit for the generator. Generator short current and
generator overcurrent alarms are based on this setpoint.
Setpoint: CT Ratio
Group
Basic Settings
Range [units]
1 ... 10000 [A/5A]
Related
applications
All
Description
Gen-set current transformers ratio.
Setpoint: EF CT Ratio
Group
Basic Settings
Range [units]
1 ... 10000 [A/5A]
Related
applications
MINT
Description
Defines current transformer ratio for current measuring input of IC-NT CT-
BIO7 extension module if used.
Setpoint: Im/EF CT Ratio
Group
Basic Settings
Range [units]
1 ... 10000 [A/5A]
Related
applications
SPtM
Description
Defines mains current transformer ratio for current measuring input of IC-NT
CT-BIO7 extension module if used.
