InteliCompact
NT
, SW version 2.1
InteliCompact-NT-2.1-Reference Guide.pdf, ©ComAp – May 2015
Timer 1 will be activated at this time on selected day(s). Learn more about
exercise timers in a separate chapter.
This setpoint adjusts the duration that Timer 1 will be active within one cycle.
Learn more about exercise timers in a separate chapter.
No Func, Mode OFF, MFail Blk, TEST, TEST OnLd [-]
It is possible to choose among the following 5 (for SPtM) or 3 (for MINT)
Timer functions. The binary output Exerc Timer 1 is always activated when
the Timer is active regardless of chosen Timer function.
MINT Only
There is no other function besides binary output Exerc Timer1
activation
When this option is chosen the Timer output is also internally
connected to the Remote OFF binary input
When this option is chosen the Timer directly starts gen-set (in
AUT mode)
There is no other function besides binary output Exerc Timer1
activation
When this option is chosen the Timer output is also internally
connected to the Remote OFF binary input
When this option is chosen the Timer output is also internally
connected to the MainsFailBlock binary input.
When this option is chosen the Timer output is also internally
connected to the Remote TEST binary input.
When this option is chosen the Timer output is also internally
connected to the Rem TEST OnLd binary input.
