ComAp InteliCompact NT Reference Guide

InteliCompact
NT
, SW version 2.1
InteliCompact-NT-2.1-Reference Guide.pdf, ©ComAp – May 2015
31
LeRoy-Somer: R 128
18VAC
From
generator
OUT1
OCOM
iG-
AVRi
230/400VAC
0VAC
AVRI
AO GND
4
5
AO GND
AVRI
IG-
AVRi
TRANS
AVRi output is connected instead Remote voltage trimmer 470 Ω to
terminals 4 and 5.
AVRi trim to minimum counter
clockwise.
Volt/PF ctrl:
AVR Bias = 50%
LeRoy-Somer: R 221, R 222
18 VAC
from generator
iG-
AVRi
230/ 400VAC
0 VAC
OUT1
OUT2
AO GND
AVRI
AO GND
AVRI
IG-
AVRi
TRANS
Module R726 is not required.
AVRi trim to minimum counter
clockwise +5%.
Volt/PF ctrl:
AVR Bias = 24%
LeRoy-Somer: R 250
18VAC
From
generator
OUT1
OCOM
iG-
AVRi
230/400VAC
0VAC
AVRI
AO GND
AO GND
AVRI
J2
IG-
AVRi
TRANS
AVRi trim to minimum counter
clockwise.
Volt/PF ctrl:
AVR Bias = 50%
