InteliDrive DCU Industrial 3.4.0 Global Guide
236
Related FW 3.4.0 Related applications AS
Comm object 67
Description
Engine coolant temperature, which is displayed at the first controller screen.
Note: Configure COOLANT TEMP (PAGE 236) (LAI card in DriveConfig) to display the value at the first
controller screen.
Coolant Temp
6 back to List of LAI
Related FW 3.4.0 Related applications AS, SS
Comm object 78
Description
Analog input for fuel level in percentage.
Fuel Level
6 back to List of LAI
Related FW 3.4.0 Related applications AS, SS
Comm object 68
Description
AI influences directly Speed Request (page 256) register when configured without ramp. In the case of
sensor fail (out of range) is Speed request = 0.0% for PRP and 50.0% (=Nominal RPM) for AUX. There is
expected range of values 0.0 … 100.0% for this Logical Analog input.
See Speed Request (page 256) charts for (page 257) and (page 257) modes.
Requested RPM
6 back to List of LAI
Related FW 3.4.0 Related applications AS
Comm object 69
Description
Actual engine torque in %, received from J1939.
Engine Torque
6 back to List of LAI
