Compaq LTE Elite - Page 155

16. Remove the six screws that attach the system board to the computer base
enclosure (Figure 4-47).
IMPORTANT: To ensure proper alignment when replacing the system board,
replace the screw noted as [1], then replace the screw noted
as [2], then replace the other four screws (Figure 4-47).
