Compaq LTE Elite - Page 284

7. Remove the screws from the PCMCIA card sensor emitter and receiver
frames (Figure 9-40).
8. Remove the receiver [1] and disconnect its cable [2] (Figure 9-40).
9. Remove the emitter [3] and disconnect its cable [4] (Figure 9-40).
