Cosmo LS-R700 User Manual

34 3 Interface
3
ID Format (Default format)
#zz_00_J_±LLL.LLL_±AAA.AAA_±BBB.BBB_±DDD.DDD_±PPP.PPP_±EEE.EEE_±FFF.FFF_CC:GG CR
Data field
Data type
Unit
Min.
Max.
Note
Tester ID
z
2-digit decimal
--
00
99
Result
J
ASCII code
(1-digit hexadecimal)
-- 1 D
1: LL FAIL
2: Pass
4: UL FAIL
9: LL2 FAIL
C: UL2 FAIL
D: Error
Leak
L
Fixed point
Leak unit
± 000.000
± 999.000
DET UL
A
Fixed point
Leak unit
± 000.000
± 999.999
DET LL
B
Fixed point
Leak unit
± 000.000
± 999.999
ΔP
D
Fixed point
Pa
± 000.000
± 999.000
Test pressure
P
Fixed point
Test press unit
± 000.000
± 999.000
TP UL
E
Fixed point
Test press unit
± 000.000
± 999.999
TP LL
F
Fixed point
Test press unit
± 000.000
± 999.999
CH#
C
2-digit decimal
--
00
32
Checksum
G
2-digit hexadecimal
--
00
FF
I Format
#zz_00_J_±LLL.LLL_±AAA.AAA_±BBB.BBB_±DDD.D_±PPP.PPP_±EEE.EEE_±FFF.FFF_C:GG CR
Data field
Data type
Unit
Min.
Max.
Note
Tester ID
z
2-digit decimal
--
00
99
Result J
One ASCII code
(1-digit hexadecimal)
-- 1 D
1: LL FAIL
2: Pass
4: UL FAIL
9: LL2 FAIL
C: UL2 FAIL
D: Error
Leak
L
Fixed point
Leak unit
± 000.000
± 999.000
DET UL
A
Fixed point
Leak unit
± 000.000
± 999.999
DET LL
B
Fixed point
Leak unit
± 000.000
± 999.999
ΔP
D
Fixed point
daPa
± 0.000
± 00099
Test pressure
P
Fixed point
Test press unit
± 000.000
± 999.000
TP UL
E
Fixed point
Test press unit
± 000.000
± 999.999
TP LL
F
Fixed point
Test press unit
± 000.000
± 999.999
CH#
C
1 character
--
0
V
0 ~ 9, A ~ V
Checksum
G
2-digit hexadecimal
--
00
FF
DT Format
ig: 0001, -9.50, -9.50, +.000, -0009.50, 96.1, END, 00, OK, 13-03-25, 00:00:00 CR
Data field
Example
Stage Timer
0001
Fixed to “0001”.
Leak -9.50
Floating point
DPS Raw Output
-9.50
Floating point
Comp Value
+.000
Floating point
ΔP -0009.50
Fixed point
Test Pressure 96.1
Floating point
END
END
Fixed to “END”
CH#
00
2-digit decimal
Result OK
Date 13-03-25
YY-MM-DD
Time
00:00:00
HH:MM:SS
Refer to the table Result Symbols in 2.6 Printer .
