3 Interface 35
3
K Format
#zz,MM,J,±LLL.LLL,±AAA.AAA,±BBB.BBB,±SSS.SSS,±PPP.PPP,±EEE.EEE,±FFF.FFF,CC,±KKK.KKK,GGG.GGG,XX,
RRRR,YYYY-MM-DD,HH:MM:SS,:GG CR
Data field
Data type
Unit
Min.
Max.
Note
Tester ID
z
2-digit decimal
--
00
99
Measurement Mode M 2-digit decimal --
00: Leak Test
01: Mastering
02: K(Ve) check
03: NR
Result J
One ASCII code
(1-digit hexadecimal)
-- 1 D
1: LL FAIL
2: Pass
4: UL FAIL
9: LL2 FAIL
C: UL2 FAIL
D: Error
Leak
L
Fixed point
Leak unit
± 000.000
± 999.000
DET UL
A
Fixed point
Leak unit
± 000.000
± 999.999
DET LL
B
Fixed point
Leak unit
± 000.000
± 999.999
Comp Value
S
Fixed point
Leak unit
± 000.000
± 999.999
Test pressure
P
Fixed point
Test press unit
± 000.000
± 999.000
TP UL
E
Fixed point
Test press unit
± 000.000
± 999.999
TP LL
F
Fixed point
Test press unit
± 000.000
± 999.999
CH#
C
2-digit decimal
--
00
32
K(Ve) Auto Setup
K
Fixed point
K(Ve) unit
± 000.000
± 999.999
K(Ve) Value
G
Fixed point
K(Ve) unit
000.000
+ 999.999
K(Ve) Check
X
2-digit decimal
%
00
30
00 to 30 every 1%
Error Code
R
4-digit hexadecimal
--
--
--
*1
Date
YYYY-MM-DD
--
--
--
Time
HH:MM:SS
--
--
--
Checksum
G
2-digit hexadecimal
--
00
FF
*1 Codes for errors and Corresponding Errors of LS-R700
Code
Error Description
8000
Error: 1 PS Offset Error
4000
Error: 11 ~ 16 Air Operated Valve Error
0800
K(Ve) Check NG
0400
Error: 24 K(Ve) Value Out of Range
0200
Error: 2 PS Output Out of Range
0100
Large Leak
0080
Error: 3 Test Pressure Error
0020
Error: 1 PS Offset Error
0000
Pass
L Format
#ZZ_00_J_±LbLbLb.Lb_±LdLdLd.Ld : GG CR
Data field
Data type
Unit
Min.
Max.
Note
Tester ID
z
2-digit decimal
00
99
Result J
One ASCII code
(1-digit hexadecimal)
-- 1 D
1: LL FAIL
2: Pass
4: UL FAIL
9: LL2 FAIL
C: UL2 FAIL
D: Error
Leak (BAL)
Lb
Floating point
Leak unit
± 0.000
± 00999
Leak (DET)
Ld
Floating point
Leak unit
± 0.000
± 00999
Checksum
G
2-digit hexadecimal
--
00
FF
