CHAMP-AV8 (VPX6-462) HARDWARE USER’S MANUAL CURTISS-WRIGHT
A-16 PROPRIETARY 826448 VERSION 5 MARCH 2015
CORRESPONDING VPX BACKPLANE J0 UTILITY CONNECTOR PIN
ASSIGNMENTS
Backplane J0 Pin assignments are shown below in Table A.5:
Table A.5: VPX Backplane J0 Pin Assignments
Pin Row i
Signal
Row h
Signal
Row g
Signal
Row f
Signal
Row e
Signal
Row d
Signal
Row c
Signal
Row b
Signal
Row a
Signal
1 Vs1_BP12V Vs1_BP12V Vs1_BP12V Vs1_BP12V N/C Vs2_BP12V Vs2_BP12V Vs2_BP12V Vs2_BP12V
2 Vs1_BP12V Vs1_BP12V Vs1_BP12V Vs1_BP12V N/C Vs2_BP12V Vs2_BP12V Vs2_BP12V Vs2_BP12V
3 Vs3_NC_BP_5V Vs3_NC_BP_5V Vs3_NC_BP_5V Vs3_NC_BP_5V N/C Vs3_NC_BP_5V Vs3_NC_BP_5V Vs3_NC_BP_5V Vs3_NC_BP_5V
4 GND SM2_BP_I2C1_SCL SM3_BP_I2C1_DAT GND -12V_AUX GND SYSRST_L NVMRO GND
5 GND GAP_L GA4_L GND 3.3V_AUX GND SM0_BP_I2C0_SCL SM1_BP_I2C0_DAT GND
6 GND GA3_L GA2_L GND +12V_AUX GND GA1_L GA0_L GND
7 TCK GND GND TDO TDI GND GND TMS TRST_L
8 GND REF_CLK_N REF_CLK_P GND GND BP_AUX_CLK_N BP_AUX_CLK_P GND GND
