CURTISS-WRIGHT
826448 VERSION 5 MARCH 2015 PROPRIETARY III
5 JE March 2015 Updated "Reference Documentation" on page xv.
Updated “General Description” on page 1-2.
Updated “Feature Summary” on page 1-3.
Added note to section “PCI Express Architecture” on page 1-7.
Added note to section “SRIO Fabric” on page 1-10.
Deleted section “Intelligent Peripheral Management Controller” previously on page 1-15.
Updated “XMC Site” on page 1-15.
Updated “Serial Ports” on page 1-17.
Updated “1000Base-BX Ethernet” on page 1-20.
Updated “Voltage, Current, and Temperature Sensors” on page 1-22.
Updated Figure 1.11, “Location of Voltage, Current, and Temperature Sensors (Secondary
Side),” on page 1-23.
Updated “RTC/CMOS RAM Backup Power” on page 1-24.
Updated Table 1.3, “Interrupt Input Connections,” on page 1-26.
Updated Table 1.4, “VPX Compliance Summary,” on page 1-31
Updated Table 1.11, “Summary of CHAMP-AV8 Connectors, Functions Supported,” on page
1-39.
Updated “Continuum IPC™ Library” on page 1-40.
Updated “Continuum Vector™ Library” on page 1-41.
Updated “Backplane Requirements” on page 2-2.
Updated “Detailed Power Requirements” on page 2-3.
Updated “XMC Site” on page 2-4.
Removed the caution note in “Install the XMC Module on the Basecard” on page 3-3.
Updated Table 3.7, “Summary of LED Behavior,” on page 3-15.
Updated Appendix A, "CHAMP-AV8 I/O Mapping".
Updated Table A.4, “P0 Utility Connector Signal Definitions,” on page A-15.
Updated Table A.39, “RTM SW2–SW18 Functions,” on page A-57.
Added two notes to Appendix A, "Rear Transition Module (RTM) Configuration Switches".
Updated Table B.1, “Memory Devices Available On The CHAMP-AV8,” on page B-2.
