CURTISS-WRIGHT HARDWARE INSTALLATION
826448 VERSION 5 MARCH 2015 PROPRIETARY 3-9
Front Panel Cable
J3 Connector
(EIA-232)
When connected to the front panel of the CHAMP-AV8, CBL-462-FPL-000 provides access to
EIA-232 Node B Serial Port 0 via the J3 connector on the cable. The pin assignments of the J3
(Female DB-9) connector are as follows:
Front Panel Cable
J4 Connector
(Ethernet Port A)
When connected to the front panel of the CHAMP-AV8, CBL-462-FPL-000 provides access to
Ethernet Port A via the J4 connector on the cable, on boards with the front panel Ethernet
factory build option. The pin assignments of the J4 (Female RJ45) modular jack are as follows:
Table 3.3: CBL-462-FPL-000 EIA-232 Node B Serial Port 0 (J3) Signal Mapping
Signal Name From P1 Pin To J3 Contact Comments
RS232_B0_TX 13 2
RS232_B0_RX 14 3
RS232-GND 1 5
The CHAMP-AV8 serial ports do not provide access to the CTS and RTS signals. Therefore,
software handshaking (XON/XOFF) must be used.
The CHAMP-AV8 EIA-232 serial channels are configured as DCE (Data Communications
Equipment). The EIA-232 serial channels on personal computers and terminals are
configured as DTE, therefore a null modem is NOT required for communication between the
CHAMP-AV8 and a PC terminal.
Table 3.4: CBL-462-FPL-000 Ethernet Port A (J4) Signal Mapping
Signal Name From P1 Pin To J4 Contact Comments
ENET_A_TRD_P0 6 1 Twisted pair 1
ENET_A_TRD_N0 19 2 Twisted pair 1
ENET_A_TRD_P1 5 3 Twisted pair 2
ENET_A_TRD_N1 18 6 Twisted pair 2
ENET_A_TRD_P2 4 4 Twisted pair 3
ENET_A_TRD_N2 17 5 Twisted pair 3
ENET_A_TRD_P3 3 7 Twisted pair 4
ENET_A_TRD_N3 16 8 Twisted pair 4
