CHAMP-AV8 (VPX6-462) HARDWARE USER’S MANUAL CURTISS-WRIGHT
3-18 PROPRIETARY 826448 VERSION 5 MARCH 2015
Bottom of
PWB
DS3 Green Node A
1000Base-BX
MDI/Copper-side
interface
link status bit 0
OFF – Indicates the
1000Mbps link is down.
This LED is expected to
stay off during normal oper-
ation for 1000Base-BX
N/A
Bottom of
PWB
DS2 Green Node A
1000Base-BX
MDI/Copper-side
interface
link status bit 1
ON – Indicates the link is
established and there is no
transmit and receive activity.
Flashing – Indicates the link
is established and there is
transmit and receive activity.
OFF – Indicates the
1000Mbps link is down
Bottom of
PWB
DS1 Green Node A
1000Base-BX
MDI/Copper-side
interface
link status bit 2
ON – Indicates the
1000Mbps link is estab-
lished and maintained
OFF – Indicates the
1000Mbps link is down
Bottom of
PWB
DS6 Green Node B
1000Base-BX
MDI/Copper-side
interface
link status bit 0
OFF – Indicates the
1000Mbps link is down
This LED is expected to
stay off during normal oper-
ation for 1000Base-BX
N/A
Bottom of
PWB
DS5 Green Node B
1000Base-BX
MDI/Copper-side
interface
link status bit 1
ON – Indicates the link is
established and there is no
transmit and receive activity
OFF – Indicates the
1000Mbps link is down
Bottom of
PWB
DS4 Green Node B
1000Base-BX
MDI/Copper-side
interface
link status bit 2
ON – Indicates the
1000Mbps link is estab-
lished and maintained
OFF – Indicates the
1000Mbps link is down
Bottom of
PWB
DS35 Green Indicates SATA activ-
ity on Node A
on-board Solid State
Drive or an external
SATA drive. This
does not indicate link
status.
ON – Indicates activity on
the SATA link.
OFF – Indicates no SATA
activity
N/A
Bottom of
PWB
DS36 Green Indicates SATA activ-
ity on Node B
on-board Solid State
Drive or an external
SATA drive. This
does not indicate link
status.
ON – Indicates activity on
the SATA link.
OFF – Indicates no SATA
activity
N/A
Table 3.7: Summary of LED Behavior (Continued)
Location Reference
Designator
Color LED
Purpose/
Function
Behavior during
Normal Operation or
Feature in Use
Behavior during
Abnormal Operation
or Feature Not in Use
