Daedong DK4520 - Inflation Pressure

4
4
-
55
FUNCTION DESCRIPTION AND OPERATING TIPS
Always maintain the proper tire ination pressure. Make sure the tire pressure
does not exceed the pressure recommended in the manual.
INFLATION PRESSURE
Item Tire sizes Ination pressure
Front
Agri.
8-16, 6PR 235 kPa (2.4 kg/cm², 34 psi)
9.5-16, 6PR 216 kPa (2.2 kg/cm², 31 psi)
260/70R16 240 kPa (2.44 kgf/cm², 34.7 psi)
280/70R16 240 kPa (2.44 kgf/cm², 34.7 psi)
Ind. 305/70R16.5 400 kPa (4.07 kgf/cm², 57.8 psi)
Rear
Agri.
12.4-24, 6PR 157 kPa (1.6 kg/cm², 22 psi)
12.4-24, 8PR 216 kPa (2.2 kg/cm², 31 psi)
13.6-24, 6PR 157 kPa (1.6 kg/cm², 22 psi)
280/85R24 160 kPa (1.63 kg/cm², 23 psi)
320/85R24 160 kPa (1.63 kg/cm², 23 psi)
340/85R24 160 kPa (1.63 kg/cm², 23 psi)
360/70R24 160 kPa (1.63 kg/cm², 23 psi)
380/70R24 160 kPa (1.63 kg/cm², 23 psi)
Ind. 360/80R24 400 kPa (3.26 kg/cm², 46.3 psi)
NOTE
• Keep the front tire pressure to
maximum when using the front
end loader or front suitcase
weights.
• If tires with a di󰀨erent size from
the ones above mentioned in the
table are installed, contact the
KIOTI dealer for the front/rear
wheel speed ratio. Improper front/
rear wheel speed ratio can result
in excessive wear of tires.
