FUNCTION DESCRIPTION AND OPERATING TIPS
SINGLE BRAKE LIGHT
This lamp indicates the single brake
condition. This comes on when the
brake pedal interlock is released.
(1) Brake Pedal Interlock
TD2O424C
D21O439A
ENGINE OIL PRESSURE WARNING
LAMP
This lamp comes on when the en-
gine oil pressure or oil level is low.
This lamp is turned On when the key
switch is turned On before starting the
engine but turned O after starting the
engine. If this lamp comes on while
driving, stop the engine immediately
and check the engine oil level.
If this lamp comes on even with the
specified engine oil level, have the
tractor checked by your local KIOTI
dealer or workshop immediately.
TD2O425C
IMPORTANT
•
If driving with the brake pedal
interlock released (Using single
brake) on a road or at a high
speed, it can lead to a rollover.
Follow the instruction.
•
If the single brake light is il-
luminated on the instrument
cluster, the brake pedals are
disconnected so either brake
pedal can be used.
•
In a normal operating condition,
keep the interlock to the Lock
position.
