Daedong DK4520 - Fixation Points for Front End Loader

57
7
-
11
3-POINT HITCH IMPLEMENT AND LOADER OPERATION
FIXATION POINTS FOR FRONT END LOADER
[Front axle frame] [Flywheel housing] [Rear axle & transmission]
WARNING
• When you do install the front loader, certainly mount the bolt for mounting bracket at indicated point.
D21O611A
※
Both of left and right side is same.
