DAELIM DAYSTAR Service Manual

14-1
Rear Wheel/Rear Brake/Suspension
Service Information ………………14-1
Troubleshooting ……………………14-2
Rear Wheel …………………………14-3
Rear Brake …………………………14-6
Rear Brake Pedal……………………14-8
Rear Cushion ………………………14-8
Rear Fork ……………………………14-10
14. Rear Wheel/Rear Brake/Suspension
Service Information
General
● Note the assembling direction of the bolts.
Specifications
Torque Values
Rear Brake Arm Bolt 1.0kgf-m
Rear Axle Nut 8.8kgf-m
Rear Shock Absorber Mounting Upper Bolt 3.4kgf-m
Rear Shock Absorber Mounting Lower Bolt 3.4kgf-m
Rear Fork Pivot Bolt 4.5kgf-m
Final Driven Sprocket Nut 5.9kgf-m
Item Standard Service Limit
Axle shaft runout 0.2(0.008)
Rear wheel rim
Radial 2.0(0.08)
runout
Axial 2.0(0.08)
Rear brake drum I.D. 130(5.12) 131(5.16)
Rear brake lining thickness 4.0(0.16) 2.0(0.08)
Rear Cushion Spring Free Length 206.7
Unit: mm(in)
14

DAELIM DAYSTAR Specifications

General

Fuel System	Carburetor
Front Suspension	Telescopic Fork
Front Brake	Disc
Rear Brake	Drum
Engine Type	4-Stroke, Air-cooled
Displacement	124 cc
Transmission	5-speed
Fuel Capacity	12.5 liters
Weight	125 kg
Rear Suspension	Dual shock absorbers
