DAELIM DAYSTAR - 17. Ignition System; Ignition System

17-1
Ignition System
Service Information ………………17-1
Troubleshooting ……………………17-2
C.D.I Unit ……………………………17-3
Ignition Coil Inspection ……………17-4
Pulse Generator ……………………17-5
A.C. Generator Inspection ………17-5
Ignition Timing Inspection ………17-6
17. Ignition System
Service Information
General
Inspect the ignition system in proper sequence based on the troubleshooting.
Dropping or giving a shock to the C.D.I unit causes a trouble.
There should be battery voltage with the ignition and engine stop switched ON. Turn the main switch
OFF while serving.
C.D.I ignition system is used and it can not be adjusted.
Couplers are connected to other couplers which have same colour.
Coil standard resistance may not be obtained due to the different measuring circumstances.
Specifications
Tools
Measuring tools
Digitalcircuit tester
Circuit tester
Inspection adapter
Spark adapter
Item Standard
Primary Coil 0.21
0.02
Pulse generator coil resistance 20 (68 ) 95-135
A.C generator coil resistance 20 (68 ) 100-140
8 BTDC / 1,400(rpm)
28
BTDC / 3,900(rpm)
17
5 1.25
K
3.1 0.1
K
Ignition coil
resistance
20
(68 )
Secondary
Coil
F mark
Full advance
Ignition timing
With the spark
plug cap
Withot the spark
plug cap
