DAELIM DAYSTAR Service Manual

3-15
Maintenance
 Measure the tread depth at the center of the
tire.
 Replace the tire when the tread depth reaches
the following limits:
Minimum Tread Depth: 4mm (0.16 in)
8.5mm (0.3 in)
Steering Head Bearings
 Check that the control cables do not interfere
with handle bar rotation.
 Raise the front wheel off the ground. Check
that the handle bar moves freely from side to
side. If the handle bar moves unevenly,
bends, or has vertical movement, inspect the
cables and electric code wires. If the handle
bar moves too freely, adjust the steering head
bearings.
NOTE

DAELIM DAYSTAR Specifications

General

Fuel System	Carburetor
Front Suspension	Telescopic Fork
Front Brake	Disc
Rear Brake	Drum
Engine Type	4-Stroke, Air-cooled
Displacement	124 cc
Transmission	5-speed
Fuel Capacity	12.5 liters
Weight	125 kg
Rear Suspension	Dual shock absorbers
