DAELIM DAYSTAR Service Manual

3-6
Maintenance
 Make sure if there is no deterioration and
damage in the air cleaner element. Replace
damaged parts.
 The element is a viscous type which contains
oil. Therefore do not use compressed air to
clean the air cleaner element.
 Assemble the Air cleaner element in the
reverse order of removal
Spark Plug
 Remove the spark plug cap and spark plug.
 Check any dirt, damage from around the spark
plug bases. If necessary, clean away the dirt
from around the spark plugs with a plug
cleaner or a wire brush.
 Measure the new spark plug using a wire-type
feeler gauge. Adjust the gap by bending the
side electrode carefully.
Pure Plug : CR8EH-9
Spark Plug Gap : 0.8~0.9mm
 Install the plug by turning with finger.
Tighten it with plug wrench.
Torque: 1.1kgf.m(11N.m)
Install the spark plug caps
Valve Clearnance
 Perform valve inspection/adjustment with the
engine at normal operating temperature (Below
35 / 95)
Remove the cylinder head cover. Align the
“T” mark on the flywheel with the index mark
on the left crank case cover, turning the
flywheel to the left.
At this time, the piston should be placed on the
groove of the compression stroke.
Element
Element
Element
Element
Element
ElementElement
Element
Element
Element
Element
Element
Element
Check the Washer
For damage
Check the Plug
for Cracks
Check the Plug
for Clearance,
Contamination
Deposit
0.8~0.9mm
A.C Generator Cap
A.C Generator Cap
A.C Generator Cap
A.C Generator Cap
A.C Generator Cap
A.C Generator CapA.C Generator Cap
A.C Generator Cap
A.C Generator Cap
A.C Generator Cap
A.C Generator Cap
A.C Generator Cap
A.C Generator Cap
NOTE
NOTE
NOTE

DAELIM DAYSTAR Specifications

General

Fuel System	Carburetor
Front Suspension	Telescopic Fork
Front Brake	Disc
Rear Brake	Drum
Engine Type	4-Stroke, Air-cooled
Displacement	124 cc
Transmission	5-speed
Fuel Capacity	12.5 liters
Weight	125 kg
Rear Suspension	Dual shock absorbers
