DAELIM DAYSTAR Service Manual

3-5
Maintenance
Carburetor Choke
 Make sure if there is no deterioration, damage
or kinking in the choke cable. Check for
smooth chock lever operation at any adjusting
position.
 Pull the choke lever forward all the way up to
fully closed. Make sure that the choke valve is
fully closed by moving the choke arm If
necessary, adjust the choke valve up to the fully
opened position by loosening the choke cable
clamp and moving the choke cable cover.
 Depress the choke lever forward up to the fully
opened position. Make sure that the choke
valve is fully opened by checking the operation
between the choke arm and cable cover.
 Recheck the carburetor choke free play.
Air Cleaner
 Loosen the four screw, and remove the air
cleaner case cover.
 Loosen the three screw, and remove the air
cleaner element.
Choke Lever
Choke Lever
Choke Lever
Choke Lever
Choke Lever
Choke Lever
Choke Lever
Choke Lever
Choke Lever
Choke Lever
Choke Lever
Choke Lever
Fuel Cock
Fuel Cock
Fuel Cock
Fuel Cock
Fuel Cock
Fuel Cock
Fuel Cock
Fuel Cock
Fuel Cock
Fuel Cock
Fuel Cock
Fuel Cock
Choke Cable
Choke Cable
Choke Cable
Choke Cable
Choke Cable
Choke Cable
Choke Cable
Choke Cable
Choke Cable
Choke Cable
Choke Cable
Choke Cable
Fuel Tube
Fuel Tube
Fuel Tube
Fuel Tube
Fuel Tube
Fuel Tube
Fuel Tube
Fuel Tube
Fuel Tube
Fuel Tube
Fuel Tube
Fuel Tube

DAELIM DAYSTAR Specifications

General

Fuel System	Carburetor
Front Suspension	Telescopic Fork
Front Brake	Disc
Rear Brake	Drum
Engine Type	4-Stroke, Air-cooled
Displacement	124 cc
Transmission	5-speed
Fuel Capacity	12.5 liters
Weight	125 kg
Rear Suspension	Dual shock absorbers
