19-5
Lights/Switches/Horn
Pull out the bulb and replace.
Assembly is done in the reverse order of
disassembly.
Winker Bulb
Loosen the screw and remove the winker unit.
Remove the bulb in bulb socket by turning
toward anti-clockwise
Take off the bulb by turning toward anti-
clockwise, and replace it.
Assembly is done in the reverse order of
disassembly.
