DAELIM DAYSTAR Service Manual

17-2
Ignition System
Troubleshooting
No spark at plug
Poorly connected, broken or shorted wires
- Between A.C. generator and C.D.I unit
- Between C.D.I unit and ignition coil
- Between ignition coil and plug
Faulty main switch
Faulty ignition coil
Faulty C.D.I unit
Faulty A.C. generator
Faulty pulse generator
Engine starts but runs poorly
Ignition primary circuit
- Faulty ignition coil
- Loose or bare wire
Secondary circuit
- Faulty plug
- Faulty high tension code
Timing advance incorrect
- Faulty A.C. generator
- Faulty C.D.I unit
- Faulty pulse generator

DAELIM DAYSTAR Specifications

General

Fuel System	Carburetor
Front Suspension	Telescopic Fork
Front Brake	Disc
Rear Brake	Drum
Engine Type	4-Stroke, Air-cooled
Displacement	124 cc
Transmission	5-speed
Fuel Capacity	12.5 liters
Weight	125 kg
Rear Suspension	Dual shock absorbers
