DAELIM DAYSTAR Service Manual

1-3
General Information
Item Specifications
Overall Length 2,240mm
Overall Width 860mm
Overall Height 1,140mm
Dimensions Wheel Base 1,505mm
Seat Height 720mm
Ground clearance 135mm
Dry Weight 147.5kgf
Curb Weight 341kgf
Type Double Cradle
Front Suspension Stroke Telescopic fork 140mm
Rear Suspension Stroke Swingarm 35mm
Front Tire Size 90/90 - 18 (Tubeless)
Rear Tire Size 130/90 - 15 (Tubeless)
Tire Pressure 1 Person Front 2.00kgf/cm
2
(200kPa)
Rear 2.00kgf/cm
2
(200kPa)
Frame 2 Person Front 2.00kgf/cm
2
(200kPa)
Rear 2.00kgf/cm
2
(200kPa)
Front Brake Hydraulic Disk
Rear Brake Drum Brake
Fuel Capacity 17.3
Fuel Reserve Capacity 2.9
Caster Angle 32
Trail Length 147mm
Front Fork Oil Capacity 280cm
3
Type Oil / Air Cooled 4-stroke
SOHC Engine
Cylinder Number, arrangement 1 Cylinder, 15
Bore and Stroke 56.5 X 49.5mm
Displacement 124.1cm
3
Comparison Ratio 11.5:1
Valve Train SOHC Chain Drive
Oil Capacity 1.2 After Disassembly
1.15  After Draining and Oil Filter Change
Engine 1.1 After Draining
Lubrication System Forced Pressure Splash Type
Air Cleaner Viscose Oil Wet Filter
Cylinder compression 14kgf/cm
2
(550rpm)
Intake Value Opens 6BTDC
Closes 22ABDC at 1.12mm Lift
Exhaust Value Opens 24BBDC
Closes 4BTDC at 1.12mm Life
Valve Clearance Intake 0.120.02mm(0.0050.001 in)
(a cooling-off period) Exhaust 0.120.02mm(0.0050.001 in)
Engine Dry Weight 32.3kg
Specifications

DAELIM DAYSTAR Specifications

General

Fuel System	Carburetor
Front Suspension	Telescopic Fork
Front Brake	Disc
Rear Brake	Drum
Engine Type	4-Stroke, Air-cooled
Displacement	124 cc
Transmission	5-speed
Fuel Capacity	12.5 liters
Weight	125 kg
Rear Suspension	Dual shock absorbers
