DAELIM DAYSTAR Service Manual

1-4
General Information
Item Specifications
Carburetor Type Piston Valve/24mm(0.94 in)
Setting Mark VL125 B
Main Jet #102
Carburetor Slow Jet #38
Pilot Screw Initial Setting 2 1/4
Float level 19mm
Idle Speed 1,400100(rpm)
Clutch Hydraulic, Multi-plate
Transmission Type Constant Mesh Transmission
Primary Reduction 3.650(73/20)
Secondary Reduction 3,000(42/14)
Gear Ratio 1st 3.083(37/12)
Drive Train Gear Ratio 2nd 1.882(32/17)
Gear Ratio 3rd 1.380(29/21)
Gear Ratio 4th 1.095(23/21)
Gear Ratio 5th 0.923(24/26)
Gearshift Pattern Left foot operated return system
1-N-2-3-4-5
Ignition CDI Ignition
Ignition Timing “F” Mark 8BTDC / 1,400(rpm)
Full Advance 28BTDC / 3,900(rpm)
AC Generator 90W / 5,000(rpm)
Battery Capacity 12V 9AH
Spark Plug CR8EH-9
Spark Plug Gap 0.8 -0.9mm
Fuse Capacity 15A
Starting System Kick/Starter Motor
Electrical Headlight (High/Low Beam) 12V 60W/55W
Winker 12V 10W4
Tail/Stop Lights 12V 5W/21W
Meter Light 12V 3W/3.4W(1.7W2)
Neutral Indicator Lamp 12V 1.7W
High Beam Pilot Lamp 12V 1.7W

DAELIM DAYSTAR Specifications

General

Fuel System	Carburetor
Front Suspension	Telescopic Fork
Front Brake	Disc
Rear Brake	Drum
Engine Type	4-Stroke, Air-cooled
Displacement	124 cc
Transmission	5-speed
Fuel Capacity	12.5 liters
Weight	125 kg
Rear Suspension	Dual shock absorbers
