1-5
General Information
Item Q’ty
Thread dia Torque
Remark
Oil Filter Screen Cap 1 36 1.5(15)
Oil Filter Relief Valve Oval Screw 1 10 1.2(12)
Oil Filter Cover Socket Bolt 3 6 1.1(11)
Oil Pump Mounting Bolt 2 6 1.1(11)
Valve Adjusting Screw Lock Nut 4 5 1.1(11)
Drive Sprocket 2 6 1.2(12)
Engine Hanger Bolt(Front) 2 8 2.7(27)
Engine Hanger Bolt(Front 1, Rear 2) 3 10 4.9(49)
Clutch Lock Nut 1 16 6.5(65) Apply Engine Oil
Drum Stopper Arm Bolt 1 6 1.2(12)
Primary Drive Gear Bolt 1 16 6.5(65) Apply Engine Oil
R Crank Case Cover Bolt 11 6 1.1(11)
Kick Starter Pedal Bolt 1 8 2.2(22)
Gear Change Arm Bolt 1 6 1.2(12)
Flywheel Bolt 1 10 5.5(55) Apply Engine Oil
Starter Clutch Socket Bolt 3 8 3.2(32)
Apply a locking nut agent
Cam Chain Tensioner Pivot Bolt 1 8 1.1(11)
Spark Plug 1 10 1.1(11)
Cam Shift Holder 8mm nut 4 8 2.0(20) Apply Engine Oil
Cam Chain Tensioner Mounting Bolt 2
6 1.2(12)
Cam Chain Tensioner Sealing Screw
16 0.4(4)
Cylinder Head Cover Bolt 2 6 1.0(10)
Crank Shaft Hole Cap 1 30 0.8(8)
Timing Hole Cap 1 14 0.6(6)
L Crank Case Cover Bolt 7 6 1.1(11)
Main Shaft Bearing Setting Plate 2 6 1.2(12)
Apply a locking nut agent
Crank Case Bolt 11 6 1.1(11)
Starter Motor Terminal Nut 1 6 1.2(12)
Cylinder(Oil Through Bolt) 2 12 3.2(32)
Radiator(Oil Through Bolt) 2 12 3.2(32)
Torque Values
Engine
Item Q’ty
Thread dia Torque
Remark
Handle Holder Bolt 2 10 2.6(26)
Steering Stem Nut 1 22 7.4(74)
Steering top Thread Nut 1 22 1.8(18)
With a Starting torque
0.3(3)
With a Finishing torque
Front Fork Top Bridge Bolt 2 7 1.1(11, 8)
Front Fork Bottom Bridge Bolt 2 8 3.3(33)
Front Fork Socket Bolt 2 8 2.0(20)
Apply a locking nut agent
Front Fork Tube Cap 2 26 2.3(23)
Front Axle Nut 1 14 5.9(59)
Front Wheel Stud Bolt 5 6 0.6(6, 4.3)
Apply a locking nut agent
Ignition Switch Bolt 2 8 3.3(33)
Front Brake Disk Nut 6 8 4.2(42) Self lock nut
Frame
(mm)
kgf.m,(N.m)
(mm)
kgf.m,(N.m)
To Next Page
