DAELIM DAYSTAR Service Manual

1-6
General Information
Torque specifications listed above are for important fastener. Other should be tighten to the standard
torque values below.
SH(Small Head): 6mm Bolt of 8mm Flange Head.
Type
Torque
Type
Torque
kgf-m N.m kgf-m N.m
15mm Bolt, nut 0.45~6 4.5~6 5mm Screw 0.35~0.5 3.5~5
16mm Bolt, nut 0.8~1.2 8~12 6mm Screw&Flange 0.7~1.1 7~11
bolt (SH TYPE)
18mm Bolt, nut 1.8~2.5 18~25 6mm flange bolt, nut 1.0~1.4 10~14
10mm Bolt, nut 3.0~4.0 30~40 8mm flange bolt, nut 2.4~3.0 24~30
12mm Bolt, nut 5.0~6.0 50~60 10mm flange bolt, nut 3.5~4.5 35~45
Item Q’ty
Thread dia Torque
Remark
Brake Caliper Bracket Bolt 2 8 3.0(30)
Brake Caliper Bleed Valve 1 8 0.6(6)
Brake Pad pin Bolt 2 8 (1.8, 13)
Master Cylinder Reservoir Cap Screw 240.13(1.3)
Brake Hose Bolt 2 10 3.4(34)
Brake Lever Pivot Bolt 1 6 1.0(10, 7)
Brake Lever Pivot Lock Nut 1 6 1.0(10, 7)
Rear Axle Nut 1 14 8.8(88)
Final Driven Sprocket Nut 4 10 5.9(59)
Rear Brake Arm Bolt 1 6 1.0(10)
Rear Shock Absorber Upper Bolt 1 10 3.4(34)
Rear Shock Absorber Lower Bolt 1 10 3.4(34)
Rear Fork Pivot Bolt 1 12 4.5(45) Self lock nut
Rear Brake Pedal Bolt 1 8 2.2(22)
Chain Tensioner Flange Nut 1 8 3.6(36)
(mm)
kgf.m,(N,m)

DAELIM DAYSTAR Specifications

General

Fuel System	Carburetor
Front Suspension	Telescopic Fork
Front Brake	Disc
Rear Brake	Drum
Engine Type	4-Stroke, Air-cooled
Displacement	124 cc
Transmission	5-speed
Fuel Capacity	12.5 liters
Weight	125 kg
Rear Suspension	Dual shock absorbers
