DAELIM DAYSTAR Service Manual

7-1
A.C Generator / Starter Clutch
7. A.C Generator / Starter Clutch
Service Information …………………7-1
A.C Generator ………………………7-2
Starter Clutch ………………………7-7
Service Information
General
● This section covers removal and installation of the A.C. generator.
● Refer to section 16 for inspection of the A.C. generator.
● The A.C. generator/starter clutch service may be done with the engine in the frame.
Specification
Item Standards Service Unit
O.D. 42.195-42.208(1.6612-1.6617) 42.180(1.658)
Starter Driven Gear
I.D 22.022-22.010(0.8670-0.8665) 22.100(0.870)
Starter Idle Gear I.D 10.045 -10.028(0.3942-0.3948) 10.100(0.393)
Starter Idle Gear Shaft O.D 9.991-10.100(0.3933-0.3937) 9.97(0.393)
Reduction Gear I.D 10.013-10.045(0.3942-0.3955) 10.100(0.393)
Reduction Gear Shaft I.D 9.991-10.100(0.3933-0.3937) 9.97(0.393)
Torque Values
Flywheel Bolt 5.5kgf-m(55N.m)
Starter Clutch Socket Bolts 3.2kgf-m(32N.m)
Left Crank Case Cover Bolt 1.1kgf-m(11N.m)
Tools
Common
Flywheel Puller
Flywheel Holder
Unit:mm(in)
7

DAELIM DAYSTAR Specifications

General

Fuel System	Carburetor
Front Suspension	Telescopic Fork
Front Brake	Disc
Rear Brake	Drum
Engine Type	4-Stroke, Air-cooled
Displacement	124 cc
Transmission	5-speed
Fuel Capacity	12.5 liters
Weight	125 kg
Rear Suspension	Dual shock absorbers
