DAELIM DAYSTAR Service Manual

4-12
Fuel System
Pilot Screw Adjustment
1. Turn each pilot screw clockwise until it seats
lightly and back it out to the specification
given.
Initial Opening : 2
 Damages to the pilot screw seat will occur if
the pilot screw is tightened against the seat.
2. Warm up the engine to operating temperature.
Adjust the number of turns to the 1,400
100rpm with the throttle stop screw.
3. Turn the pilot screws out by
turn each until
engine speed does not increase.
4. Perform steps 2 and 3.
5. Adjust the idle speed with the throttle stop
screw.
6. Pull the throttle grip lightly. If the idle speed
changes, perform steps from 2 to 5.
Pilot Screw
Pilot Screw
Pilot Screw
Pilot Screw
Pilot Screw
Pilot ScrewPilot Screw
Pilot Screw
Pilot Screw
Pilot Screw
Pilot Screw
Pilot Screw
Pilot Screw
!
CAUTION
△

DAELIM DAYSTAR Specifications

General

Fuel System	Carburetor
Front Suspension	Telescopic Fork
Front Brake	Disc
Rear Brake	Drum
Engine Type	4-Stroke, Air-cooled
Displacement	124 cc
Transmission	5-speed
Fuel Capacity	12.5 liters
Weight	125 kg
Rear Suspension	Dual shock absorbers
