Dahua DH-VTO9341D User Manual

Web Interface 65
 Export Config
Click Export Config to export the system config, network config, and video config to local
storage, and the exported config can be used to restore config or import into other VTO.
 Import Config
Click Import Config to import the local config files into the VTO; you can restore or sync
data with this function.
 Default All
Click Default All, and then confirm. The VTO will reboot, and all the parameters except IP
address will be reset to the factory settings.
7.3.6 Wiegand
You can configure the parameters of Wiegand sensors.
Select System Config > Local Config > Wiegand Step 1
The Wiegand interface is displayed. See Figure 7-10.
Wiegand Figure 7-10
Configure Wiegand parameters. See Table 7-5 for the details. Step 2
Table 7-5 Wiegand parameter
Parameter
Description
Mode
Supports single Wiegand input or output.
Output Type
ID or Card
TransMode
Select transmitting speed from 26 bit, 34 bit, and 64 bit. The bigger the
value is, the faster the transmission will be.
Pulse Step (µs)
It is 1000 by default.
Pulse Width (µs)
It is 200 by default.
Click OK to save. Step 3
LAN Config 7.4
7.4.1 LAN Config
This section introduces how to configure server type and group call.
Select System Config > LAN Config > LAN Config. Step 1
The LAN Config interface is displayed. See Figure 7-11.

Dahua DH-VTO9341D Specifications

General

Brand	Dahua
Model	DH-VTO9341D
Category	Intercom System
Language	English
