Web Interface 87
Add mapping relation Figure 7-43
Configure parameters. See Table 7-18 for the details. Step 2
Table 7-18 UPnP parameter description
Parameter
Description
Turn
on/Turn off
Select Turn on, and then the mapping relation is enabled.
Select Turn off, then the mapping relation will not be enabled, and you
can select it later in the list.
Server
Name
The name of the server.
Protocol
You can select from TCP and UDP. For the transmission stability, TCP is
recommended.
Inport
The port
on the VTO
that need
to be
mapped.
 Try to use port number between 1024 to 5000 and not
between 1 to 255 and 256 to 1023 when mapping ports
with router to avoid conflict.
 When mapping multiple devices to the external ports,
do the planning in advance to avoid mapping different
devices to the same external port.
 Make sure the ports you are using are not being used or
constrained.
 The external ports of TCP and UDP must be the same.
Outport
The port
on the
router that
the VTO
port is
being
mapped to.
Click OK to finish configuration. Step 3
7.12.4 Modifying Service
You can modify the mapping relations in the list.
Click . Step 1
The Modify interface is displayed. See Figure 7-44.
