Web Interface 70
number you configured on the VTH.
If there are master VTH and extension VTH being used, the
short number of the master VTH should be "room
number#0", and the extension VTH to be #1, #2, #3 and so
on.
Click OK to finish configuration. Step 3
7.5.2.2 Modifying VTH
Click .
Step 1
The Modify interface is displayed. See Figure 7-17.
Modifying VTH Figure 7-17
Modify all the parameters of the VTH. See Table 7-9. Step 2
Click OK to finish. Step 3
7.5.2.3 Deleting VTH
Click to delete VTH one by one; click Clear to delete all the VTH.
7.5.3 Card Info
This section introduces how to define master card, report loss, cancel report, and modify card
user.
Before using this function, make sure the VTO already has authorized card, otherwise, there
will be no card. For the card registration, see "6.4.3 Issuing Card."
Select System Config > Device Manager > 8001-Indoor Station Manager, and then click ,
The Card Info interface is displayed. See Figure 7-18.
