User’s Manual EM11A015B
intelligent Touch Manager
39
(7) LAN LINK (Green)
This LED indicates whether the LAN connection between the intelligent Touch Manager and the
connected hardware is correct. The LED is On when the connection is correct.
(8) DIII MONITOR (Yellow)
This LED ashes when data transmission occurs on the DIII-NET communication line.
(9) MONITOR key/LED (Orange/Green)
Press this switch to turn on/off the monitor. Doing so also causes the LED color to change as
follows.
Off: Indicates that the power is off.
On (Orange): Indicates that the monitor is on.
On (Green): Indicates that the monitor is on.
(10) RESET//
Restart switch for restarting the intelligent Touch Manager.
(11) USB socket cover (side)
USB memory port.
Do not use the socket for any purpose other than connecting a USB memory.
NOTE
