(7) Area hierarchy indicator
Displays the hierarchical level of the currently displayed area.
(8) Top, Down, and Up buttons
Top button: Displays the area and management points at the Top.
Down button: Moves into the selected area and displays the areas and management points there.
Up button: Moves up one hierarchical level from that of the currently displayed area and displays
the areas and management points there.
(9) Type combo box
Selects the type of the areas and management points to display.
Types available for selection are: All, Indoor, Ventilator, Chiller, Outdoor, Dio, Analog, and Pulse.
The displayed items vary depending on the management point type you selected.
(10) Icon switch button
Switches the screen to a view in which settings of areas and management points are displayed
using icons.
(11) Information button
Displays the legend for an icon or contact information for inquiries regarding the system.
(12) Selected area/management point status
Displays the name, icon, and lter sign of the selected area or management point.
(13) Room Temp/Operation Mode/Changeover Option indicator
Displays the room temperature and settings of the selected indoor unit. Not displayed for areas.
When the selected indoor unit is in error, it displays only the error code.
NOTE
(14) Details button
Displays the Detailed Information screen for the selected area or management point.
(15) On/Off combo box
Starts/Stops the selected area or management point.
When the optional Setback function is enabled, it displays Start, SB Low, SB High, or Stop.
NOTE
(16) Setpoint spin box
Sets up the temperature for the indoor unit of the selected area, or the selected indoor unit.
