Dalsa Falcon 4-CLHS Series User Manual

Falcon™ 4-CLHS Series Technical Specifications  103
General Purpose Output 3 Fast Switching
GPO 3 supports a fast switching mode with ground of the user load connected to pin 3 (General
Input/Output Common Ground). Note, GPO 1 and GPO 2 do not support fast switching. Test
conditions are with front plate temperature ~60C.
Output Common
Power
Output
R
load
t
d1 (us
) t
rise (
µs) t
d2 (
µs) t
fall (
µs)
V
out (
V)
Current
Test (ohm)
Leading
Delay
Rise Time
Trailing
Delay
Fall Time
5V
8 mA 561 1 0.7 3.64 0.5 4.53
16 mA 277 1 0.7 3.48 0.659 4.45
24 mA 182 1 0.7 3.32 0.65 4.37
12V
8 mA 1444 0.934 0.2321 2.88 0.949 11.49
16 mA 713 0.945 0.2563 2.86 0.42 11.41
24 mA 467 0.952 0.2739 2.78 0.224 11.33
24V
8 mA 2930 0.81 0.2079 3.542 1.639 23.57
16 mA 1464 0.803 0.2244 2.908 0.981 23.47
24 mA 970 0.82 0.2222 2.6 0.616 23.39
Output Characteristics, FA-HM10-M4485, FA-HM11-M4405, FA-HM10-M8205
General Purpose Outputs 1, 2, 3 and 4 Fast Switching
On these models, all general-purpose outputs support a fast switching mode with ground of the
user load connected to pin 3 (General Input/Output Common Ground). Test conditions are with
front plate temperature ~60C.
Output Common
Power
Output
R
load
t
d1 (us
) t
rise (
µs) t
d2 (
µs) t
fall (
µs)
V
out (
V)
Current
Test (ohm)
Leading
Delay
Rise Time
Trailing
Delay
Fall Time
5V
8 mA 561 1 0.7 3.64 0.5 4.53
16 mA 277 1 0.7 3.48 0.659 4.45
24 mA 182 1 0.7 3.32 0.65 4.37
12V
8 mA 1444 0.934 0.2321 2.88 0.949 11.49
16 mA 713 0.945 0.2563 2.86 0.42 11.41
24 mA 467 0.952 0.2739 2.78 0.224 11.33
24V
8 mA 2930 0.81 0.2079 3.542 1.639 23.57
16 mA 1464 0.803 0.2244 2.908 0.981 23.47
24 mA 970 0.82 0.2222 2.6 0.616 23.39
