Falcon™ 4-CLHS Series Operational Reference  83
Metadata Availability
The Metadata Availability field (pixels [7:15]) determines which metadata is available, as a bit
field. When a field is present, the corresponding bit is set to 1 in the availability bit field.
When a field is not present (availability set to 0), it is removed from the structure.
Feature Mask (Hex) Available bit
Exposure Time
2 1
Cycling Current Set
4 2
FFC Current Active Set
8 3
LUT Current Active Set
10 4
Test Image User-Defined Index
20 5
Line Status All
40 6
Iris Aperture Control
80 7
Gain (Analog Gain and Digital Gain)
100 8
Black Level
200 9
Image Offset (Offset X and Offset Y)
400 10
Image Size
800 11
Timestamp
1000 12
Frame ID
2000 13
Binning
4000 14
Exposure Delay
8000 15
Counter Value at Reset
10000 16
Multi-ROI
8000000 27
Test Image Selector
10000000 28
Serial Number
20000000 29
Device User ID
40000000 30
Pixel Format
80000000 31
Digital Gain (raw)
Digital gain is expressed in the metadata in its raw format. To convert from this raw format to an
actual gain value use this formula:
𝐺𝑎𝑖𝑛 =
  ()
  ()
Example: a digital gain raw value of 4402 and a factory gain raw value of 2201 would translate to
an actual gain of 2.
