Falcon™ 4-CLHS Series Operational Reference  41
Data Processing Feature Descriptions
Display Name Feature & Values Description
Device
Version
& View
Processing Pixel Size processingPathBpp Pixel size in bits per pixel during processing.
1.00
Guru
DFNC
10 Bits/Pixel Bpp10 Sensor output data path is 10 bits per pixel.
FPN Correction Mode FPNCorrectionMode Sets the mode for the FPN correction.
1.00
Expert
DFNC
Off Off
Optical Black Reference FPN correction
applied if available in the current active set.
Active Active
FPN is enabled. If Optical Black Reference
FPN correction is available in the current
active set it is also applied.
Calibration Calibration
When selected, the camera is configured for
FPN correction calibration.
FPN Correction Active Set FPNCorrectionActiveSet Specifies the current set of FPN coefficients
to use. This feature cannot be changed
during acquisition.
1.00
Expert
DFNC
Factory FPNFactory Sets the factory FPN coefficient table as the
current FPN set.
User Set 1 FPNUser1 Sets User Set 1 coefficient table as the
current FPN set.
User Set 2 FPNUser2 Sets User Set 2 coefficient table as the
current FPN set.
Target Exposure Range
Min
FPNCalibrationTargetExposureMin
Sets the minimum exposure time, in μs, for
FPN calibration.
1.00
Guru
DFNC
Target Exposure Range
Max
FPNCalibrationTargetExposureMax
Sets the maximum exposure time, in μs, for
FPN calibration.
1.00
Guru
DFNC
Optical Black Reference FPNCalibrationOpticalBlackReference Sets the enable state of dark current
correction using values generated on a row-
by-row basis using shielded pixels.
1.00
Guru
DFNC
Off
Off
Row-by-row dark current correction is
disabled. When the FPN Correction Mode is
set to active only ADC related correction is
applied.
Active Active Row-by-row dark current correction
coefficients are generated during calibration
and included in the FPN correction for the
selected user set.
Optical Black Reference
Calibration Offset
FPNCalibrationOpticalBlackReferenceOffset Sets the offset to apply to the optical black
reference correction to ensure that values
are above 0.
1.00
Guru
DFNC
Calibration FPN FPNCalibrationCalibrate Performs Fixed Pattern Noise (FPN)
calibration by reducing to zero dark pixel
current using a pixel offset.
1.00
Guru
DFNC
Save FPN Calibration FPNCalibrationSave
Save the calibration performed by
FPNCalibrationCalibrate to the active set.
1.00
Guru
DFNC
Defective Pixel
Replacement Mode
defectivePixelReplacementMode
Sets the enable state for defective pixel
replacement.
1.01
Expert
DFNC
Off Off Disable defective pixel replacement.
Active Active Enable defective pixel replacement.
Defective Pixel
Replacement Map
Current Active Set
defectivePixelReplacementMapCurrentActiveSet
Sets the defective pixel replacement map set
to use.
1.01
Expert
DFNC
Factory Map FactoryMap
Factory default defective pixel replacement
map.
User Set 1 UserMap1 User defective pixel replacement map.
