Falcon™ 4-CLHS Series Falcon4-CLHS Specifications  11
Falcon4-CLHS Specifications: M4480, M4400
Model specific specifications and response graphics for the Lince 11M series are provided here.
Supported Features
M4480 M4400
Resolution 4480 x 2496 4480 x 2496
Sensor E2V Lince 11M E2V Lince 11M
Pixel Size 6 µm x 6 µm
Shutter Type Full frame electronic global shutter function
Full Well charge > 38 ke
Maximum Frame Rate (8-bit) 600 fps (burst acquisition) 330 fps
CLHS configuration (X-Protocol) 7-Lanes 4-Lanes
Pixel Format (Mono) Monochrome 8 or 10-bit
Sensor Synchronization Synchronous mode via external trigger signal or free running
Trigger to Exposure Minimum
delay (Synchronous Exposure)
9 µs (8-bit)
Trigger to Exposure Minimum
delay (Reset Exposure)
9 µs (8-bit)
Trigger to Exposure Start jitter
(Synchronous Exposure)
Up to 1 line time
Trigger to Exposure Start jitter
(Reset Exposure)
0 µs
Exposure Time Minimum
(see “exposureTimeActual” in
Sensor Control)
5 µs
Horizontal Line Time 0.655 µs
Min. Time from End of Exposure to
Start of Next Exposure
4.47 µs
Readout Time
(full frame size)
Number of rows must be a multiple of 8
8-bit / fast readout active:
20.3e-9*(128)*(number of rows+16) / 4+20.3e-9*(128)
8-bit / fast readout off:
20.3e-9*(137)*(number of rows+16) / 4+20.3e-9*(137)
10-bit / fast readout active:
20.3e-9*(154)*(number of rows+16) / 4+20.3e-9*(154)
10-bit / fast readout off:
20.3e-9*(165)*(number of rows+16) / 4+20.3e-9*(165)
Black offset control Yes (in DN)
Gain Control In-sensor Analog Gain (1x to 4x), FPGA Digital Gain
Defective Pixel Replacement Yes, up to 1022 pixel positions
Multi-ROI Support Yes
Output Dynamic Range (dB) > 59.5
SNR (dB) 46
