Falcon™ 4-CLHS Series Falcon4-CLHS Specifications  13
Falcon4-CLHS Specifications: M8200
Model specific specifications and response graphics for the Emerald 67M series are provided here.
Supported Features
M8200
Resolution 8192 x 8192
Sensor E2V Emerald 67M
Pixel Size 2.5 µm x 2.5 µm
Shutter Type Full frame electronic global shutter function
Full Well charge > 5 ke
Maximum Frame Rate (8-bit) 90 fps
CLHS configuration (X-Protocol) 7-Lanes
Pixel Format (Mono) Monochrome 8-bit or 10-bit
Sensor Synchronization Synchronous mode via external trigger signal or free running
Trigger to Exposure Minimum
delay (Synchronous Exposure)
8 µs (8-bit)
Trigger to Exposure Minimum
delay (Reset Exposure)
8 µs (8-bit)
Trigger to Exposure Start jitter
(Synchronous Exposure)
Up to 1 line time
Trigger to Exposure Start jitter
(Reset Exposure)
0 µs
Exposure Time Minimum
(see “exposureTimeActual” in
Sensor Control)
8 µs
Horizontal Line Time 2.68 µs
Min. Time from End of Exposure to
Start of Next Exposure
7.5 µs
Readout Time
(full frame size)
Number of rows must be a multiple of 2
10 980 µs (8-bit)
12 148 µs (10-bit)
Black offset control Yes (in DN)
Gain Control In-sensor Analog Gain (1x to 4x), FPGA Digital Gain
Defective Pixel Replacement Yes, up to 6132 pixel positions
Multi-ROI Support Yes
Output Dynamic Range (dB) > 52.25
SNR (dB) 36
