Falcon™ 4-CLHS Series Operational Reference  57
Maximum Frame Rate Examples
Example frame rates for M4480 and M4400 models.
Conditions:8-bit, minimum exposure time is 5 µs, Fast readout mode: active, exposure alignment:
synchronous.
Vertical Lines Acquired M4480* M4400
2496 600 335
1248 1 187 664
624 2 325 1 303
312 4 465 2 512
160 8 064 4 587
80 14 084 8 130
40 22 222 13 157
24 29 411 17 543
16 34 482 20 833
8 41 666 26 315
*framerate will be lower if camera is set to cycle exposure time
Example frame rates for M8200 model.
Conditions: 8-bit, minimum exposure time is 8 µs, exposure alignment: synchronous.
Vertical Lines Acquired M8200
8192 91
6144 121
4096 181
1024 711
512 1 386
256 2 637
128 4 805
40 11 053
16 17 127
8 20 967
4 23 615
Horizontal Cropping (Partial Scan)
Crop the acquisition horizontally by grabbing fewer pixels on each horizontal line. Horizontal offset
(OffsetX) defines the start of the acquired video line while horizontal width (Width) defines the
number of pixels per line.
