Falcon™ 4-CLHS Series Falcon4-CLHS Specifications  9
Falcon4-CLHS Specifications
The common specifications listed first are followed by model specific tables of functional features
and timing details.
Common Specifications
Camera Controls
Communication Protocol GenCP (GenICam GenCP compliant software), CLHS X Protocol
Synchronization Modes Free running, Triggered (via CX4 cable or external I/O)
Exposure Control Internal – Programmable via the camera API
External – Timed Trigger or Trigger Width modes supported via I/O
Exposure Time Minimum /
Maximum
5 µs – 0.5 s (M4480, M4400)
8 µs – 0.5 s (M8200)
Exposure Modes Timed: Programmable in increments of 1µs (minimum time (in µs) is model specific)
Trigger Width: Pulse controlled via external Trigger pulse width
Input / Output Ports
2 input / 3 output ports (FA-HM00-M4485), opto-coupled
2 input / 4 output ports (FA-HM10-M4485, FA-HM11-M4405, FA-HM10-M8205), opto-
coupled
Features
Gain In-sensor gain (sensor-specific), digital gain
Defective Pixel Replacement Up to 1022 entries
Binning 2x2 (horizontal and vertical)
Lens Shading Correction 1 user coefficient set
LUT Programmable LUT (lookup table) up to 10-bit
Counter and Timer 1 Counter and 1 Timer. User programmable, acquisition independent, with event
generation, and can control Output I/O pins
Test image Internal generator with choice of static patterns
Metadata Metadata Output at the end of the Images (also known as GenICam Chunk Data)
Cycling Mode Automatic cycling between 64 camera setups
Multi ROI Multiple regions of interest (Max number of ROIs: 32 without cycling, 8 with cycling)
User settings Select factory default or either of two user saved camera configurations
CLHS Link Speed 10.3 Gb/s per Lane
4 Data Lanes (FA-HM11-M4405)
7 Data Lanes (FA-HM10-M4485, FA-HM10-M4405, FA-HM10-M8205)
Back Focal Distance
12 mm (with M42 lens mount)
Optical Interface
Sensor Alignment (Relative to sides of camera)
Flatness 50 µm
 y 200 µm (Parallelism vs. front plate)
x ± 100 µm (Cross-Scan Direction)
y ± 100 µm (In-Scan Direction)
z ± 300 µm (Along optical axis)
 z ± 1.0° (Rotation around optical axis)
